Building An Immutable Cloud Infrastructure On Alibaba Cloud

Introduction

Immutable Application Platform

Immutable File System

/etc/demo/demo.conf[main]
env = dev
port = 8000
/var/demo/demo.py:#!/usr/bin/env python import SimpleHTTPServer
import SocketServer
import ConfigParser
config = ConfigParser.RawConfigParser()
config.read('/etc/demo/demo.conf')
env = config.get('main', 'env')
port = config.getint('main', 'port')
Handler = SimpleHTTPServer.SimpleHTTPRequestHandler httpd = SocketServer.TCPServer(("", port), Handler) print("serving %s at port %d" % (env, port))
httpd.serve_forever()
$ yum install -y ostree
$ mkdir -p /etc/demo && cd /etc/demo
$ ostree --repo=.demo init
$ ostree --repo=.demo commit --branch=dev ./
8d7cefc677593c16ecd9eada965fb1ac53d6ae96a6af9fef49a22d164a06e6e2
$ ostree --repo=.demo refs
dev
$ ostree --repo=.demo ls dev
d00755 0 0 0 /
-00644 0 0 29 /demo.conf
d00755 0 0 0 /.rdemo
$ ostree --repo=.demo cat dev /demo.conf
[main]
env = dev
port = 8000
chmod +x /var/demo/demo.py
/var/demo/demo.py
serving dev at port 8000
$ cat /etc/demo/demo.conf
[main]
env = uat
port = 80
$ ostree --repo=.demo commit --branch=uat ./
3aca353878a754a887a0308ff5ca6f8ad86057a2175e3f0b194ff51c5e471116
/var/demo/demo.py
serving uat at port 80
$ ostree --repo=.demo cat dev /demo.conf
[main]
env = dev
port = 8000
$ ostree --repo=.demo cat uat /demo.conf
[main]
env = uat
port = 80

Immutable Package Management

$ rpm-ostree status
$ rpm-ostree upgrade
$ systemctl reboot
$ openssl version
OpenSSL 1.0.1e-fips 11 Feb 2013
$ rpm-ostree install openssl
Checking out tree 67d659b... done
Inactive requests:
openssl (already provided by openssl-1:1.0.2k-12.el7.x86_64)
Enabled rpm-md repositories: base updates extras
Updating metadata for 'base': [=============] 100%
rpm-md repo 'base'; generated: 2018-11-25 16:00:34
Updating metadata for 'updates': [=============] 100%
rpm-md repo 'updates'; generated: 2019-01-24 13:56:44
Updating metadata for 'extras': [=============] 100%
rpm-md repo 'extras'; generated: 2018-12-10 16:00:03
Importing metadata [=============] 100%
Resolving dependencies... done
Checking out packages (2/2) [=============] 100%
Running pre scripts... 0 done
Running post scripts... 1 done
Writing rpmdb... done
Writing OSTree commit... done
Copying /etc changes: 22 modified, 8 removed, 41 added
Transaction complete; bootconfig swap: no; deployment count change: 0
Freed: 39.0 MB (pkgcache branches: 2)
Run "systemctl reboot" to start a reboot
$ openssl version
OpenSSL 1.0.2k-fips 26 Jan 2017
$ rpm-ostree rollback
Moving '67d659bc257b7d47f638f9d7d2146401b85eec7c7eef0122196d72c70553ae66.0' to be first deployment
Transaction complete; bootconfig swap: no; deployment count change: 0
Removed:
openssl-1.0.2k-12.el7.x86_64
Run "systemctl reboot" to start a reboot
$ systemctl reboot $ openssl version
OpenSSL 1.0.1e-fips 11 Feb 2013

Immutable Provisioner

$ atomic install registry.access.redhat.com/rhel7/rsyslog
Pulling registry.access.redhat.com/rhel7/rsyslog:latest ...

Creating directory at /host//etc/pki/rsyslog
Installing file at /host//etc/rsyslog.conf
Installing file at /host//etc/sysconfig/rsyslog
Installing file at /host//etc/logrotate.d/syslog
$ atomic run registry.access.redhat.com/rhel7/rsyslog
docker run -d --privileged --name rsyslog --net=host --pid=host -v
/etc/pki/rsyslog:/etc/pki/rsyslog ...

Summary
