Four Major Technologies Behind the Microservices Architecture

Image for post
Image for post

Internet applications have evolved from a single-application architecture to the service-oriented architecture and then to microservices. As microservices are constantly upgraded, stable service interoperability is becoming increasingly important because distributed systems must deal with network latency and instability. Microservices are designed to ensure service idempotence by controlling concurrencies through distributed locks. The stable operation of a microservices system depends on caching, degradation, and throttling.

Continuous business development results in an increasing number of subsystems divided by different business domains. Each business system requires components for caching, throttling, distributed locks, and idempotence. The distributed-tools component, currently not open-source, includes the basic components required by distributed systems.

The distributed-tools component provides two easy-to-use Spring Boot starters based on Tair and Redis, respectively. To use a Redis cache, add the following configuration to application.properties:

redis.extend.hostName=127.0.0.1
redis.extend.port=6379
redis.extend.password=pwdcode
redis.extend.timeout=10000
redis.idempotent.enabled=true

In the following sections, we will be describe how you can use caching, throttling, distributed locks, and idempotence.

Caching

The distributed-tools component provides the CacheEngine operation, whose implementation varies depending on whether Tair or Redis is used. The CacheEngine operation is defined as follows.

public String get(String key);    /**
* 获取指定的key对应的对象,异常也会返回null
*
* @param key
* @param clazz
* @return
*/
public <T> T get(String key, Class<T> clz);
/**
* 存储缓存数据,忽略过期时间
*
* @param key
* @param value
* @return
*/
public <T extends Serializable> boolean put(String key, T value);
/**
* 存储缓存数据
*
* @param key
* @param value
* @param expiredTime
* @param unit
* @return
*/
public <T extends Serializable> boolean put(String key, T value, int expiredTime, TimeUnit unit);
/**
* 基于key删除缓存数据
*
* @param key
* @return
*/
public boolean invalid(String key);

The GET method queries keys, the PUT method stores cached data, and invalid is used to delete cached data.

Throttling

Common throttling algorithms include fixed window, sliding window, leaky bucket, and token bucket. Currently, the distributed-tools component only implements the fixed window algorithm based on counters. The implementation is as follows.

/**
* 指定过期时间自增计数器,默认每次+1,非滑动窗口
*
* @param key 计数器自增key
* @param expireTime 过期时间
* @param unit 时间单位
* @return
*/
public long incrCount(String key, int expireTime, TimeUnit unit);
/**
* 指定过期时间自增计数器,单位时间内超过最大值rateThreshold返回true,否则返回false
*
* @param key 限流key
* @param rateThreshold 限流阈值
* @param expireTime 固定窗口时间
* @param unit 时间单位
* @return
*/
public boolean rateLimit(final String key, final int rateThreshold, int expireTime, TimeUnit unit);

Throttling is implemented by using the rateLimit method of CacheEngine. expireTime only sets the fixed window time, rather than the sliding window time. The distributed-tools component provides the RateLimitTemplate template with the Execute method used to directly implement throttling.

/**
* @param limitKey 限流KEY
* @param resultSupplier 回调方法
* @param rateThreshold 限流阈值
* @param limitTime 限制时间段
* @param blockDuration 阻塞时间段
* @param unit 时间单位
* @param errCodeEnum 指定限流错误码
* @return
*/
public <T> T execute(String limitKey, Supplier<T> resultSupplier, long rateThreshold, long limitTime,
long blockDuration, TimeUnit unit, ErrCodeEnum errCodeEnum) {
boolean blocked = tryAcquire(limitKey, rateThreshold, limitTime, blockDuration, unit);
if (errCodeEnum != null) {
AssertUtils.assertTrue(blocked, errCodeEnum);
} else {
AssertUtils.assertTrue(blocked, ExceptionEnumType.ACQUIRE_LOCK_FAIL);
}
return resultSupplier.get();
}

The distributed-tools component also provides @RateLimit to annotate RateLimit as follows.

@Retention(RetentionPolicy.RUNTIME)
@Target(ElementType.METHOD)
@Documented
public @interface RateLimit {
/**
* 限流KEY
*/
String limitKey();
/**
* 允许访问的次数,默认值MAX_VALUE
*/
long limitCount() default Long.MAX_VALUE;
/**
* 时间段
*/
long timeRange();
/**
* 阻塞时间段
*/
long blockDuration();
/**
* 时间单位,默认为秒
*/
TimeUnit timeUnit() default TimeUnit.SECONDS;
}

The following code implements throttling based on annotation:

@RateLimit(limitKey = "#key", limitCount = 5, timeRange = 2, blockDuration = 3, timeUnit = TimeUnit.MINUTES)
public String testLimit2(String key) {
..........
return key;
}

You can add the preceding annotation to any method within the interception range of Spring AOP to enable throttling. For example, the sample code uses the key parameter for throttling. As such, requests may be blocked for three minutes if more than five requests are sent every two minutes.

Distributed Locks

The distributed-tools component provides a distributed lock with the following features:

  • Mutex: The distributed lock requires mutex of different threads in different node processes.
  • Reentrancy: A thread on a node can fetch the distributed lock twice.
  • Lock timeout: The distributed lock supports lock timeout to prevent deadlock and refreshes the timeout period by using the demon thread of asynchronous heartbeats to prevent deadlock in special scenarios, such as the timeout of full garbage collection due to deadlock.
  • High performance and high availability: High performance is required by locking and unlocking. High availability is required to prevent distributed lock failures. Degradation is supported.
  • Blocking and non-blocking: The distributed lock supports lock, trylock, and tryLock(long timeOut).
  • Fair lock and non-fair lock (not supported): Fair locks are fetched in the order of lock requests. Non-fair locks are unordered. Currently, the distributed lock provided by the distributed-tools component does not support this feature.

The distributed lock provided by distributed-tools is easy to use. The provided lock template, DistributedLockTemplate, can be directly called through the following static method:

/**
* 分布式锁处理模板执行器
*
* @param lockKey 分布式锁key
* @param resultSupplier 分布式锁处理回调
* @param waitTime 锁等待时间
* @param unit 时间单位
* @param errCodeEnum 指定特殊错误码返回
* @return
*/
public static <T> T execute(String lockKey, Supplier<T> resultSupplier, long waitTime, TimeUnit unit,
ErrCodeEnum errCodeEnum) {
AssertUtils.assertTrue(StringUtils.isNotBlank(lockKey), ExceptionEnumType.PARAMETER_ILLEGALL);
boolean locked = false;
Lock lock = DistributedReentrantLock.newLock(lockKey);
try {
locked = waitTime > 0 ? lock.tryLock(waitTime, unit) : lock.tryLock();
} catch (InterruptedException e) {
throw new RuntimeException(String.format("lock error,lockResource:%s", lockKey), e);
}
if (errCodeEnum != null) {
AssertUtils.assertTrue(locked, errCodeEnum);
} else {
AssertUtils.assertTrue(locked, ExceptionEnumType.ACQUIRE_LOCK_FAIL);
}
try {
return resultSupplier.get();
} finally {
lock.unlock();
}
}

Idempotence

Idempotence is divided into two dimensions.

  1. Spatial idempotence indicates the range of an idempotent object, which may be an individual or organization, or a specific transaction or a type of transaction.
  2. Temporal idempotence indicates the guaranteed time of idempotence, which may be several hours, several days, or an unlimited time period.

Many operations are performed in an actual system, and each operation is supposed to have the same effect or return the same result each time it is performed. Some common scenarios are as follows.

  1. When requests for the same data are repeatedly sent by the frontend, the backend returns the same result for each of these requests.
  2. When a payment request is initiated, the payment center makes only one deduction from the related account, even when a network interruption or system exception occurs.
  3. An SMS message with the same content is sent only once to the same user.
  4. Only one order is created for a business request, even when this request is retried.
  5. Message idempotence is processed based on message identifiers.

We need to understand the design of the idempotence feature provided by distributed-tools before using it.

Image for post
Image for post
  • Idempotent Key Extraction Capability: Fetch a Unique Idempotent Key: An idempotent key can be fetched by adding the IdempotentTxId and IdempotentTxIdGetter annotations to any method that requires idempotence. If you process services only by using an idempotent template, you must configure a unique idempotent key.
  • Distributed Lock Service: Provides Global Locking and Unlocking Capabilities: The idempotence provided by distributed-tools must use the built-in distributed lock to ensure concurrency and uniqueness. The distributed lock provides reliable and stable locking and unlocking capabilities.
  • High-performance Write and Query Capabilities: Query and Store Idempotent Results: The idempotence of distributed-tools provides storage based on Tair and Redis and supports injection to IdempotentService through Spring dependencies by customizing tier-1 and tier-2 storage. We recommend that you use Tair MDB as tier-1 storage and LDB or TableStore as tier-2 storage. Tier-1 storage ensures high performance, and tier-2 storage ensures high reliability. For a parallel query on tier-2 storage, the result of the fastest idempotent query is returned. Data is written to tier-2 storage in parallel to improve performance.
  • High-availability Idempotent Write and Query Capabilities: Improve Fault Tolerance to Prevent Service Impact due to Idempotent Storage Exceptions: The idempotence provided by distributed-tools supports high-availability tier-2 storage, which minimizes service unavailability due to the low probability of faults. If tier-2 storage is abnormal, fault tolerance is implemented for services. When an indeterminate error occurs, a retry policy is implemented and an idempotent method is executed.

Writes and queries are isolated in tier-1 and tier-2 storage. An error in tier-1 storage has no impact on service implementation.

Next, let’s discuss how to use the idempotence provided by distributed-tools. The following table lists the idempotent annotations provided by common-api.

Image for post
Image for post

The idempotent interceptor fetches an idempotent ID in the following order of priority:

  1. The idempotent interceptor determines whether the spelKey property of the Idempotent annotation is null. If it is not null, the idempotent interceptor creates an idempotent ID based on the Spring expression defined by spelKey.
  2. The idempotent interceptor determines whether the IdempotentTxId annotation is included in the parameters. If it is, the idempotent interceptor directly fetches the parameter values to create an idempotent ID.
  3. The idempotent interceptor fetches the object attributes of parameters through reflection and determines whether the IdempotentTxId annotation is included in these object attributes. If it is, the idempotent interceptor fetches the object attributes to create an idempotent ID.
  4. If the idempotent interceptor fails to fetch an idempotent ID in the preceding three cases, it fetches the methods of parameter objects through reflection and determines whether the IdempotentTxIdGetter annotation is defined. If it is, the idempotent interceptor creates an idempotent ID through reflection.

Sample code:

@Idempotent(spelKey = "#request.requestId", firstLevelExpireDate = 7,secondLevelExpireDate = 30)
public void execute(BizFlowRequest request) {
..................
}

This sample code is used to fetch requestId from the request and use it as the idempotent key. The validity period in tier-1 storage is 7 days, and that in tier-2 storage is 30 days.

In addition to idempotent annotations, distributed-tools provides the IdempotentTemplate universal idempotent template. Before using this template, set tair.idempotent.enabled or redis.idempotent.enabled to true (the default value is false) and specify tier-1 storage to store idempotent results. Idempotent result storage is an optional setting.

Use IdempotentTemplate as follows.

/**
* 幂等模板处理器
*
* @param request 幂等Request信息
* @param executeSupplier 幂等处理回调function
* @param resultPreprocessConsumer 幂等结果回调function 可以对结果做些预处理
* @param ifResultNeedIdempotence 除了根据异常还需要根据结果判定是否需要幂等性的场景可以提供此参数
* @return
*/
public R execute(IdempotentRequest<P> request, Supplier<R> executeSupplier,
Consumer<IdempotentResult<P, R>> resultPreprocessConsumer, Predicate<R> ifResultNeedIdempotence) {
........
}
  • request: Assembles the idempotent parameter IdempotentRequest. You can set this parameter and a unique idempotent ID.
  • executeSupplier: This indicates an idempotent method logic. For example, you can use the function-type operation Supplier Callback of JDK 8 in payment and ordering scenarios.
  • resultBiConsumer: This indicates the method for processing the returned idempotent results. If the parameter value is null, the default processing method is used. If the operation is successful or the returned error code does not support retry, results are directly returned. If the returned error code supports retry, the operation is retried.

If the parameter value is not null, you can set ResultStatus to perform special logic processing on the returned idempotent results. ResultStatus indicates one of three states: (1.) Successful, (2.) Failed and Retriable, and (3.) Failed but Not Retriable.

Original Source:
