Get Started with MongoDB BI Connector in 4 Steps

Install BI Connector

wget https://info-mongodb-com.s3.amazonaws.com/mongodb-bi/v2/mongodb-bi-linux-x86_64-rhel70-v2.12.0.tgz$tar xvf mongodb-bi-linux-x86_64-rhel70-v2.12.0.tgz
mongodb-bi-linux-x86_64-rhel70-v2.12.0/LICENSE
mongodb-bi-linux-x86_64-rhel70-v2.12.0/README
mongodb-bi-linux-x86_64-rhel70-v2.12.0/THIRD-PARTY-NOTICES
mongodb-bi-linux-x86_64-rhel70-v2.12.0/example-mongosqld-config.yml
mongodb-bi-linux-x86_64-rhel70-v2.12.0/bin/mongosqld
mongodb-bi-linux-x86_64-rhel70-v2.12.0/bin/mongodrdl
mongodb-bi-linux-x86_64-rhel70-v2.12.0/bin/mongotranslate
  • The mongosqld tool receives SQL query requests and forwards the requests to MongoDB Server, which is the core of BI Connector.
  • The mongodrdl tool generates database schema information that is used for BI SQL queries.
  • The mongotranslate tool converts SQL queries to the MongoDB Aggregation Pipeline format.

Start mongosqld

mongodb-bi-linux-x86_64-rhel70-v2.12.0/bin/mongosqld --addr 127.0.0.1:3307 --mongo-uri 127.0.0.1:9555
  • addr: specifies the address of the mongosqld listener.
  • mongo-uri: specifies the address of the connected MongoDB Server.
$./bin/mongodrdl --uri=mongodb://127.0.0.1:9555/test -c coll01
schema:
- db: test
tables:
- table: coll01
collection: coll01
pipeline: []
columns:
- Name: _id
MongoType: float64
SqlName: _id
SqlType: float
- Name: qty
MongoType: float64
SqlName: qty
SqlType: float
- Name: type
MongoType: string
SqlName: type
SqlType: varchar

Use a MySQL Client to Connect to mongosqld

mysql --protocol=tcp --port=3307mysql> use test
Database changed
mysql> show tables;
+----------------+
| Tables_in_test |
+----------------+
| coll |
| coll01 |
| coll02 |
| inventory |
| myCollection |
| yourCollection |
+----------------+
6 rows in set (0.00 sec)
mysql> select * from coll01;
+------+------+--------+
| _id | qty | type |
+------+------+--------+
| 1 | 5 | apple |
| 2 | 10 | orange |
| 3 | 15 | banana |
+------+------+--------+
3 rows in set (0.00 sec)
// 对照 MongoDB 数据库里的原始数据mongo --port
mymongo:PRIMARY> use test
switched to db test
mymongo:PRIMARY> show tables;
coll
coll01
coll02
inventory
myCollection
yourCollection
mymongo:PRIMARY> db.coll01.find()
{ "_id" : 1, "type" : "apple", "qty" : 5 }
{ "_id" : 2, "type" : "orange", "qty" : 10 }
{ "_id" : 3, "type" : "banana", "qty" : 15 }

Convert SQL to Aggregation

// 导出分析的 shema 文件
$./bin/mongodrdl --uri=mongodb://127.0.0.1:9555/test -c coll01 > coll01.schema
// SQL 转换为 Aggregation
$./bin/mongotranslate --query "select * from test.coll01" --schema coll01.schema
[
{"$project": {"test_DOT_coll01_DOT__id": "$_id","test_DOT_coll01_DOT_qty": "$qty","test_DOT_coll01_DOT_type": "$type","_id": NumberInt("0")}},
]
