Setting up Spark on MaxCompute

Image for post
Image for post

By Geng Jiangtao.

Spark on MaxCompute is different to Spark’s native architecture. So, in this post, we’re going to show you how you can get Spark on MaxCompute set up elsewhere, in particular, how you can set up Spark on an Alibaba Cloud ECS server, in DataWorks, and in a local IDEA test environment.

The underlying architecture built for Spark on Alibaba Cloud is different to its native architecture, but offers full native support. Consider the two diagrams below.

Image for post
Image for post

The above diagrams show how Sparks works both in a native architecture and how it works on Alibaba Cloud. The diagram on the left shows the native Spark architecture, and the one on the right shows the architecture used for Spark on MaxCompute, which is a solution that runs on the Cupid platform. This architecture allows MaxCompute to provide Spark computing services and enable the Spark computing framework to be provided on a unified computing resource and dataset permission system.

Setting up Spark on an Alibaba Cloud ECS Server

Download the client to your local device. You can download it from this link. After you’ve downloaded it, you’ll need to upload the file to an Alibaba Cloud ECS server.

Image for post
Image for post

Next, you’ll need to decompress the file.

tar -zxvf spark-2.3.0-odps0.30.0.tar.gz

Find Spark-default.conf in the file and configure it.

# spark-defaults.conf
# 一般来说默认的template只需要再填上MaxCompute相关的账号信息就可以使用Spark
spark.hadoop.odps.project.name =
spark.hadoop.odps.access.id =
spark.hadoop.odps.access.key =
# 其他的配置保持自带值一般就可以了
spark.hadoop.odps.end.point = http://service.cn.maxcompute.aliyun.com/api
spark.hadoop.odps.runtime.end.point = http://service.cn.maxcompute.aliyun-inc.com/api
spark.sql.catalogImplementation=odps
spark.hadoop.odps.task.major.version = cupid_v2
spark.hadoop.odps.cupid.container.image.enable = true
spark.hadoop.odps.cupid.container.vm.engine.type = hyper

Download the corresponding code from GitHub, which you can find here. Then, take that code and upload it to your ECS server and decompress it.

unzip MaxCompute-Spark-master.zip

You’re want to compress the code again. Compress the code into a JAR package. Before you do this, however, ensure that Maven is installed.

cd MaxCompute-Spark-master/spark-2.x
mvn clean package

Now check that this last operation was successful. Go to view and run the JAR package.

bin/spark-submit --master yarn-cluster --class com.aliyun.odps.spark.examples.SparkPi \
MaxCompute-Spark-master/spark-2.x/target/spark-examples_2.11-1.0.0-SNAPSHOT-shaded.jar

Setting up Spark in DataWorks

Log on to the DataWorks console and click Business Flow.

Image for post
Image for post

Open a business flow and create an ODPS Spark node.

Image for post
Image for post

Upload JAR package resources. You can select the JAR package to be uploaded and submit it.

Image for post
Image for post
Image for post
Image for post
Image for post
Image for post

Configure the corresponding ODPS Spark node. Save and submit the configuration. Click Run to view its running status.

Image for post
Image for post

Setting up Spark in a Local IDEA Test Environment

Download and decompress the client and template code. You can find the client here.

Image for post
Image for post

You’ll also need the template code, which you can find on GitHub. After you’ve got the code, open IDEA and choose File and then Open… to select the template code.

Image for post
Image for post
Image for post
Image for post

Install the Scala plugin.

Image for post
Image for post
Image for post
Image for post

Configure Maven.

Image for post
Image for post

And last configure the JDK and related dependencies.

Image for post
Image for post
Image for post
Image for post
