Understanding CPU Interrupts in Linux

What Is an Interrupt?

What Are RPS and RFS?

Figure 1 Case with only RPS enabled (sourcing from the Internet)
Figure 2 Case with both RPS and RFS enabled (sourcing from the Internet)

Viewing the Number of NIC Queues

# ethtool -l eth0
Channel parameters for eth0:
Pre-set maximums:
RX: 0
TX: 0
Other: 0
Combined: 4
Current hardware settings:
RX: 0
TX: 0
Other: 0
Combined: 4
# cat /proc/interrupts
CPU0 CPU1 CPU2 CPU3
0: 141 0 0 0 IO-APIC-edge timer
1: 10 0 0 0 IO-APIC-edge i8042
4: 807 0 0 0 IO-APIC-edge serial
6: 3 0 0 0 IO-APIC-edge floppy
8: 0 0 0 0 IO-APIC-edge rtc0
9: 0 0 0 0 IO-APIC-fasteoi acpi
10: 0 0 0 0 IO-APIC-fasteoi virtio3
11: 22 0 0 0 IO-APIC-fasteoi uhci_hcd:usb1
12: 15 0 0 0 IO-APIC-edge i8042
14: 0 0 0 0 IO-APIC-edge ata_piix
15: 0 0 0 0 IO-APIC-edge ata_piix
24: 0 0 0 0 PCI-MSI-edge virtio1-config
25: 4522 0 0 4911 PCI-MSI-edge virtio1-req.0
26: 0 0 0 0 PCI-MSI-edge virtio2-config
27: 1913 0 0 0 PCI-MSI-edge virtio2-input.0
28: 3 834 0 0 PCI-MSI-edge virtio2-output.0
29: 2 0 1557 0 PCI-MSI-edge virtio2-input.1
30: 2 0 0 187 PCI-MSI-edge virtio2-output.1
31: 0 0 0 0 PCI-MSI-edge virtio0-config
32: 1960 0 0 0 PCI-MSI-edge virtio2-input.2
33: 2 798 0 0 PCI-MSI-edge virtio2-output.2
34: 30 0 0 0 PCI-MSI-edge virtio0-virtqueues
35: 3 0 272 0 PCI-MSI-edge virtio2-input.3
36: 2 0 0 106 PCI-MSI-edge virtio2-output.3
input0 indicates the network interrupt handled by the first CPU (CPU 0).
If there are multiple Alibaba Cloud ECS network interrupts, input.1, input.2, and input.3 are available.
......
PIW: 0 0 0 0 Posted-interrupt wakeup event
# for i in $(egrep "\-input."  /proc/interrupts |awk -F ":" '{print $1}');do cat /proc/irq/$i/smp_affinity_list;done
5
7
1
3
# for i in $(egrep "\-input."  /proc/interrupts |awk -F ":" '{print $1}');do cat /proc/irq/$i/smp_affinity_list;done |tr -s '\n' ','
5,7,1,3,
#sar -P 5,7,1,3 1 Refresh the usage of CPUs 5, 7, 1, and 3 every second.
# sar -P ALL 1 Refresh the usage of all CPU cores every second when a few CPU cores are being monitored, so that we can determine whether slow processing is caused by insufficient queues.
Linux 3.10.0-957.5.1.el7.x86_64 (iZwz98aynkjcxvtra0f375Z) 05/26/2020 _x86_64_ (4 CPU)
05:10:06 PM CPU %user %nice %system %iowait %steal %idle
05:10:07 PM all 5.63 0.00 3.58 1.02 0.00 89.77
05:10:07 PM 0 6.12 0.00 3.06 1.02 0.00 89.80
05:10:07 PM 1 5.10 0.00 5.10 0.00 0.00 89.80
05:10:07 PM 2 5.10 0.00 3.06 2.04 0.00 89.80
05:10:07 PM 3 5.10 0.00 4.08 1.02 0.00 89.80
05:10:07 PM CPU %user %nice %system %iowait %steal %idle
05:10:08 PM all 8.78 0.00 15.01 0.69 0.00 75.52
05:10:08 PM 0 10.00 0.00 16.36 0.91 0.00 72.73
05:10:08 PM 1 4.81 0.00 13.46 1.92 0.00 79.81
05:10:08 PM 2 10.91 0.00 15.45 0.91 0.00 72.73
05:10:08 PM 3 9.09 0.00 14.55 0.00 0.00 76.36
sar -P 1,3,5,7 1 |tail -n+3|awk '$NF<10 {print $0}'
sar -P ALL 1 |tail -n+3|awk '$NF<10 {print $0}'
# grep -i "input" /proc/interrupts
27: 1932 0 0 0 PCI-MSI-edge virtio2-input.0
29: 2 0 1627 0 PCI-MSI-edge virtio2-input.1
32: 1974 0 0 0 PCI-MSI-edge virtio2-input.2
35: 3 0 284 0 PCI-MSI-edge virtio2-input.3
# for i in $(egrep "\-input." /proc/interrupts |awk -F ":" '{print $1}');do cat /proc/irq/$i/smp_affinity_list;done
1
3
1
3
# lscpu
Architecture: x86_64
CPU op-mode(s): 32-bit, 64-bit
Byte Order: Little Endian
CPU(s): 4
On-line CPU(s) list: 0-3
Thread(s) per core: 2
Core(s) per socket: 2
Socket(s): 1
NUMA node(s): 1
# service irqbalance status
Redirecting to /bin/systemctl status irqbalance.service
● irqbalance.service - irqbalance daemon
Loaded: loaded (/usr/lib/systemd/system/irqbalance.service; enabled; vendor preset: enabled)
Active: inactive (dead) since Wed 2020-05-27 14:39:28 CST; 2s ago
Process: 1832 ExecStart=/usr/sbin/irqbalance --foreground $IRQBALANCE_ARGS (code=exited, status=0/SUCCESS)
Main PID: 1832 (code=exited, status=0/SUCCESS)
May 27 14:11:40 iZbp1ee4vpiy3w4b8y2m8qZ systemd[1]: Started irqbalance daemon.
May 27 14:39:28 iZbp1ee4vpiy3w4b8y2m8qZ systemd[1]: Stopping irqbalance daemon...
May 27 14:39:28 iZbp1ee4vpiy3w4b8y2m8qZ systemd[1]: Stopped irqbalance daemon.
# for i in $(egrep "\-input."  /proc/interrupts |awk -F ":" '{print $1}');do cat /proc/irq/$i/smp_affinity_list;done
1
3
1
3
# echo 0 >> /proc/irq/27/smp_affinity_list
# cat /proc/irq/27/smp_affinity_list
0
Each bit in the binary value represents a CPU on the server. A simple demo is shown below:
CPU ID Binary Hexadecimal
CPU 0 0001 1
CPU 1 0010 2
CPU 2 0100 4
CPU 3 1000 8
echo ff > /sys/class/net/eth0/queues/rx-0/rps_cpusThis method is similar to the method used to configure the interrupt affinity. A mask is used, and is set to a value indicating that all CPUs can be used to handle interrupts. For example:
4core, f
8core, ff
16core, ffff
32core, ffffffff
Queue 0 is configured on CPU 0 by default.
# cat /sys/class/net/eth0/queues/rx-0/rps_cpus
0
# echo f >>/sys/class/net/eth0/queues/rx-0/rps_cpus
# cat /sys/class/net/eth0/queues/rx-0/rps_cpus
f
# sysctl -a |grep net.core.rps_sock_flow_entries
net.core.rps_sock_flow_entries = 0
# sysctl -w net.core.rps_sock_flow_entries=1024
net.core.rps_sock_flow_entries = 1024
#  cat /sys/class/net/eth0/queues/rx-0/rps_flow_cnt
0
# echo 256 >> /sys/class/net/eth0/queues/rx-0/rps_flow_cnt
# cat /sys/class/net/eth0/queues/rx-0/rps_flow_cnt
256

Case Study: Adjustment in Stress Testing

Case Study: CPU Interrupt Processing Anomaly of a Customer
