Using HTTPS to Access IoT Platform from a Device

Image for post
Image for post

HTTPS Access to IoT Platform from a Device

The IoT platform supports HTTPS access from a device only in China (Shanghai). For more information on the access flow for communication using HTTP connections refer to this document.

1) Device Authentication: Token Acquisition Based on Trituple Information

To begin with, view the HTTPS server endpoint.

Image for post
Image for post
Image for post
Image for post

Consider the following sample authentication request.

POST /auth HTTP/1.1
Host: iot-as-http.cn-shanghai.aliyuncs.com
Content-Type: application/json
body: {
"version": "default",
"clientId": "mylight1000002",
"signmethod": "hmacsha1",
"sign": "4870141D4067227128CBB4377906C3731CAC221C",
"productKey": "ZG1EvTEa7NN",
"deviceName": "NlwaSPXsCpTQuh8FxBGH",
"timestamp": "1501668289957"
}

The following snippet shows the sample response.

{
"code": 0,//业务状态码
"message": "success",//业务信息
"info": {
"token": "6944e5bfb92e4d4ea3918d1eda3942f6"
}
}

2) Device Data Reporting

The HTTPS server endpoint is at .

Image for post
Image for post

Consider the following sample request.

POST /topic/a1GFjLP3xxC/device123/pub
Host: iot-as-http.cn-shanghai.aliyuncs.com
password:${token}
Content-Type: application/octet-stream
body: ${your_data}

The preceding sample request shows the following response.

{
"code": 0,//业务状态码
"message": "success",//业务信息
"info": {
"messageId": 892687627916247040
}
}

3) Node.js Case Study

Let’s take a quick look at the case study for Node.js. The following sections describe the various steps.

3.1 Create an Advanced Product

Refer to the following snapshot to create an advanced product.

Image for post
Image for post

3.2 Define Functions

Next, add product property definitions as listed in the following table.

Image for post
Image for post
Image for post
Image for post

3.3 Register a Device and Obtain Identity Trituple Information on the Devices Page

Obtain identity trituple information on the device page post registering a device as shown below.

Image for post
Image for post

3.4 Run Device Simulation Code

Now, execute the following device simulation code.

var rp = require('request-promise');
const crypto = require('crypto');
const deviceConfig = {
productKey: "替换productKey",
deviceName: "替换deviceName",
deviceSecret: "替换deviceSecret"
}
const topic = `/sys/${deviceConfig.productKey}/${deviceConfig.deviceName}/thing/event/property/post`;//1.获取身份token
rp(getAuthOptions(deviceConfig))
.then(function(parsedBody) {
console.log('Auth Info :'+JSON.stringify(parsedBody))
//2.发布物模型数据
pubData(topic, parsedBody.info.token, getPostData())
})
.catch(function(err) {
console.log('Auth err :'+JSON.stringify(err))
});
//生成Auth认证的参数
function getAuthOptions(deviceConfig) {
const params = {
productKey: deviceConfig.productKey,
deviceName: deviceConfig.deviceName,
timestamp: Date.now(),
clientId: Math.random().toString(36).substr(2),
}
//1.生成clientId,username,password
var password = signHmacSha1(params, deviceConfig.deviceSecret);
var options = {
method: 'POST',
uri: 'https://iot-as-http.cn-shanghai.aliyuncs.com/auth',
body: {
"version": "default",
"clientId": params.clientId,
"signmethod": "hmacsha1",
"sign": password,
"productKey": deviceConfig.productKey,
"deviceName": deviceConfig.deviceName,
"timestamp": params.timestamp
},
json: true
};
return options;
}
//publish Data to IoT
function pubData(topic, token, data) {
const options = {
method: 'POST',
uri: 'https://iot-as-http.cn-shanghai.aliyuncs.com/topic' + topic,
body: data,
headers: {
password: token,
'Content-Type': 'application/octet-stream'
}
}
rp(options)
.then(function(parsedBody) {
console.log('publish success :' + parsedBody)
})
.catch(function(err) {
console.log('publish err ' + JSON.stringify(err))
});
}
//模拟物模型数据
function getPostData() {
var payloadJson = {
id: Date.now(),
params: {
humidity: Math.floor((Math.random() * 20) + 60),
temperature: Math.floor((Math.random() * 20) + 10)
},
method: "thing.event.property.post"
}
console.log("===postData\n topic=" + topic)
console.log(payloadJson)
return JSON.stringify(payloadJson);
}
//HmacSha1 sign
function signHmacSha1(params, deviceSecret) {
let keys = Object.keys(params).sort();
// 按字典序排序
keys = keys.sort();
const list = [];
keys.map((key) => {
list.push(`${key}${params[key]}`);
});
const contentStr = list.join('');
return crypto.createHmac('sha1', deviceSecret).update(contentStr).digest('hex');
}

3.5 View Code Execution Results

Once the preceding code successfully executes, navigate to the following screen to finally view the results.

Image for post
Image for post
