Using Logtail to Collect Logs from NAS Mounted on Kubernetes

Sidecar NAS Collection Method

  • Step 1: Create a PV.
  • Step 2: Create a PVC.
  • Step 3: Create a Pod containing Logtail based on the following yaml template, for internal collection of a single Pod.
apiVersion: batch/v1
kind: Job
metadata:
name: nginx-log-sidecar1-demo
spec:
template:
metadata:
name: nginx-log-sidecar-demo
spec:
# Volume configuration
volumes:
- name: nginx-log
persistentVolumeClaim:
claimName: nas-pvc
containers:
# Master container configuration
- name: nginx-log-demo
image: registry.cn-hangzhou.aliyuncs.com/log-service/docker-log-test:latest
command: ["/bin/mock_log"]
args: ["--log-type=nginx", "--stdout=false", "--stderr=true", "--path=/var/log/nginx/access.log", "--total-count=1000000000", "--logs-per-sec=100"]
volumeMounts:
- name: nginx-log
mountPath: /var/log/nginx
# Sidecar container configuration of Logtail
- name: logtail
image: registry.cn-hangzhou.aliyuncs.com/log-service/logtail:latest
env:
# user id
- name: "ALIYUN_LOGTAIL_USER_ID"
value: "${your_aliyun_user_id}"
# user defined id
- name: "ALIYUN_LOGTAIL_USER_DEFINED_ID"
value: "${your_machine_group_user_defined_id}"
# config file path in logtail's container
- name: "ALIYUN_LOGTAIL_CONFIG"
value: "/etc/ilogtail/conf/${your_region_config}/ilogtail_config.json"
# env tags config
- name: "ALIYUN_LOG_ENV_TAGS"
value: "_pod_name_|_pod_ip_|_namespace_|_node_name_|_node_ip_"
- name: "_pod_name_"
valueFrom:
fieldRef:
fieldPath: metadata.name
- name: "_pod_ip_"
valueFrom:
fieldRef:
fieldPath: status.podIP
- name: "_namespace_"
valueFrom:
fieldRef:
fieldPath: metadata.namespace
- name: "_node_name_"
valueFrom:
fieldRef:
fieldPath: spec.nodeName
- name: "_node_ip_"
valueFrom:
fieldRef:
fieldPath: status.hostIP
# Share the volume with the master container
volumeMounts:
- name: nginx-log
mountPath: /var/log/nginx
# Health check
livenessProbe:
exec:
command:
- /etc/init.d/ilogtaild
- status
initialDelaySeconds: 30
periodSeconds: 30
restartPolicy: "Never"
  • The log path is the same as the log path of the collected container.
  • Note: The NAS path has been mounted to the Logtail container, so the “Docker File” option does not need to be switched ON.
__source__:  internal IP address of the pod container
__tag__:__hostname__: pod name
__tag__:__path__: log path
__tag__:__receive_time__: collection time
__tag__:__user_defined_id__: user-defined identity
__tag__:_namespace_: namaspace to which the pod belongs
__tag__:_node_ip_: IP address of the Node to which the pod belongs
__tag__:_node_name_: name of the Node to which the pod belongs
__tag__:_pod_ip_: internal IP address of the pod container
__tag__:_pod_name_: pod name

User Parameters

Single Logtail Collecting NAS Data for All Pods

apiVersion: apps/v1
kind: Deployment
metadata:
name: logtail-deployment
namespace: kube-system
labels:
k8s-app: nas-logtail-collecter
spec:
replicas: 1
selector:
matchLabels:
k8s-app : nas-logtail-collecter
template:
metadata:
name: logtail-deployment
labels:
k8s-app : nas-logtail-collecter
spec:
containers:
# Logtail configuration
- name: logtail
image: registry.cn-hangzhou.aliyuncs.com/log-service/logtail:latest
env:
# aliuid
- name: "ALIYUN_LOGTAIL_USER_ID"
value: "${your_aliyun_user_id}"
# user defined id
- name: "ALIYUN_LOGTAIL_USER_DEFINED_ID"
value: "${your_machine_group_user_defined_id}"
# config file path in logtail's container
- name: "ALIYUN_LOGTAIL_CONFIG"
value: "/etc/ilogtail/conf/${your_region_config}/ilogtail_config.json"
volumeMounts:
- name: nginx-log
mountPath: /var/log/nginx
# Volume configuration
volumes:
- name: nginx-log
persistentVolumeClaim:
claimName: pvc-test-nginx
  • Note: The “claimName: pvc-test-nginx” and “mountPath: /var/log/nginx” is to mount the /var/log/nginx of Logtail to the /nginx folder under NAS
  • For related parameter settings, see the table description in Solution 1.
apiVersion: v1
kind: Pod
metadata:
name: "test-nginx-2"
spec:
containers:
- name: "nginx-log-demo"
image: "registry.cn-hangzhou.aliyuncs.com/log-service/docker-log-test:latest"
command: ["/bin/mock_log"]
args: ["--log-type=nginx", "--stdout=false", "--stderr=true", "--path=/var/log/nginx/access.log", "--total-count=1000000000", "--logs-per-sec=100"]
volumeMounts:
- name: "nas2"
mountPath: "/var/log/nginx"
volumes:
- name: "nas2"
flexVolume:
driver: "alicloud/nas"
options:
server: "mount address of NAS"
path: "/nginx/test2"
vers: "4.0"

Original Source

--

--

--
